All-in-One Android Label Barcode Thermal Receipt Printer 2 Inch for Buy
Overview Product DescriptionMS-MLP212-E is a peelable and recyclable thermal sticker printer with a combination of ROHM
Basic Info
Model NO. | MS-MLP212-E |
Style | Black and White |
Consumable Type | Thermal Paper Roll |
Max. Paper Size | 58mm |
Character Structure | Full-width Characters Printers |
Product Name | Roll to Roll Label Printer |
Interface | USB ,RS232 |
Print Width | 56mm Max |
Print Paper Width | 35mm-60mm |
Feeding Method | Manual Feed(Horizontal 180°) |
Print Speed | 120mm/S |
Print Baud Rate | 9600.19200.38400.115200 |
Transport Package | One PC/Per Carton |
Specification | dimension: 240*130*118mm |
Trademark | Masung |
Origin | Guangdong |
HS Code | 8443321400 |
Production Capacity | 50000 Set/Sets Per Month |
Product Description
MS-MLP212-E is a peelable and recyclable thermal sticker printer with a combination of ROHM line thermal print head chip, MS-MLP212 print control board and sheet metal structure independently developed by our company.This printer has a bottom paper recovery device, paper feed button, buzzer and indicator light. The bottom paper recovery device can recycle the bottom paper into a roll while peeling off the ticket; the paper feed button can manually control the ticket issuance and print the self-test test page; the buzzer can sound an alarm when the printer reports an error; It can be used with the buzzer to accurately locate the cause of the fault; these basic humanized functions of the printer make it easier and more convenient for end users to use.
please contact me freely
Contact : Amy
s/k/y/p/e: Amy-cj3
Model | MS-MLP212-E | |
Main Control Board | MS-MLP212 | |
Print Method | Line thermal printing | |
Resolution | 203dpi | |
Dot Matrix | 448dots/line | |
Print Width | 56mm (max) | |
Print Paper Width | 35mm ~ 60mm | |
Feeding Method | Manual feed(Horizontal 180°) | |
Print Length | 100KM | |
Print Speed | 120mm/s | |
Paper Out Way | Automatic stripping | |
Print Format | Invert, underline, italic, bold, etc. | |
ASCII | 9*17,12*24 | |
Chinese | 24*24 dot | |
Print Head Temperature | Temperature Sensor | |
Joint Detection (transmitting, receiving) | Through-beam photoelectric sensor | |
Paper-out sensor | Reflective photoelectric sensor | |
Open Lid Detection | Touch the switch in place | |
Average Current | [email protected](Effective printing points 25%) | |
Peak Current | 5.8A | |
Communication Interface | RS232,USB | |
Print baud rate | 9600,19200,38400,115200 | |
Thermal paper specifications | Paper type | Self-adhesive paper roll with thermal coating |
Paper roll specifications | Inner diameter>=25mm | |
Outer diameter<=120mm | ||
Operating Temperature | -10~50ºC(No condensation) | |
Operating Humidity | 20%~85%RH(40ºC is 85%RH) | |
Storage Temperature | -20~70ºC(No condensation) | |
Storage humidity | 10%~90%RH(50ºC is 90%RH) | |
Dimensions*¹ | About D112mm * W217.5mm * H106.5mm | |
Weight*¹ | About 1.7kg | |
*¹Means without paper roll |
