58mm mini embedded Panel Mount Printer thermal receipt printer CSN-A2
Basic Info
| Model NO. | CSN-A2 |
| Style | Black and White |
| Consumable Type | N/a |
| Max. Paper Size | 58mm |
| Character Structure | Full-width Characters Printers |
| Transport Package | Carton |
| Specification | 111x65x56.5mm |
| Trademark | QIJI |
| Origin | China |
| HS Code | 8471900090 |
| Production Capacity | 10000/Month |
Product Description
58mm mini embedded Panel Mount Printer thermal receipt printer CSN-A2
Feature:This printer is ideal for interfacing with a microcontroller, you simply need a 5V-9V/12V TTL/USB/RS232 output from your microcontroller to print text, barcodes, bitmap graphics, even a QR code!
This package comes with a thermal printer including the print head (it does not require ink, a set of power and data cables, and two plastic shims for panel mounting.
2'' 58mm Industrial Embedded Panel Thermal Receipt Printer CSN-A2
Detailed Photos58mm Thermal Embedded Kiosk TTL/RS232 Receipt Printer CSN-A2 Thermal Panel Printer
2'' 58mm Industrial Embedded Panel Thermal Receipt Printer CSN-A2
Product Parameters58mm mini embedded Panel Mount Printer thermal receipt printer CSN-A2
| Model | CSN-A2 | |
| Printing Method | Thermal line printing | |
| Printing Speed | Max 90mm/s | |
| Resolution | 203dpi(8dots/mm) | |
| Effective printing width | 48mm | |
| Character | Character set | ASCII,GB2312-80(Chinese) |
| Fonts | ANK:9*17,12*24,GBK:24*24 | |
| Memory | Flash memory | 20K bytes |
| RAM | Flash:128KB SPAM:20KB | |
| Paper Spec. | Paper Type | Thermal paper |
| Paper Width | 58mm | |
| Paper thickness | 55-90μm | |
| Paper diameter | 39mm(Max) | |
| Reliability | TPH | 50km(12.5% print ratio) |
| Barcode | 1D | UPC-A, UPC-E, JAN/EAN8, JAN/EAN13, CODE39, ITF, CODEBAR, CODE128, CODE93 |
| 2D | QR code | |
| Command | Compatible with ESC/POS command set | |
| Driver/SDK | Windows Driver,Linux Driver,OPOS Driver | |
| Interface | Parallel+Serial(RS232/TTL)/Serial(RS232/TTL)+USB | |
| Power | DC5V-9V/12V | |
| Environment | Environment | Operating:0°C~50°C Storage:-20°C ~ 60°C |
| Humidity | Operating:10%RH~80%RH Storage:10%~90%RH | |
| Dimensions | Outline Dimension(W*L*H) | 111x65x56.5mm |
| Installation Port Size | 103x57mm | |
| Insert Depth | 50mm | |
Suzhou Qiji Electric specializes in designing, developing, manufacturing and marketing of printing equipment.With experienced and professional R&D team, we successfully launched a series of printing equipment, such as advanced POS receipt printers, portable printers and LCD modules, bluetooth printer, micro panel printer, KIOSK printer, barcode label printer, as well as printer mechanisms (thermal & impact type) and so on.Our products are widely used for POS/ECR, transport ticketing, instrument analyzers, KIOSK system, electronic medical equipment, self-service solution, fire safety, tax control, shopping malls, car automotive, food and beverage industries, embedded printing solutions, cinemas, highway, boarding cards, tax control system and so on.
FAQ| 1.Can I get a sample order first to test the quality and compatibility? | |
| Yes, usually we have samples in stock, customers can easily buy them for testing purpose. | |
| 2.What about delivery time? | |
| For sample, usually 3 days. For bulk order,usually 7 to 15 days,depends on order quantity. | |
| 3.How about Payment terms? | |
| For sample, Paypal, Western Union. For bulk order, T/T prepaid. | |
| 4.How about shipping methods? | |
| DHL, UPS, FedEx,China Post, etc are all ok, we will choose the economical and fast way. | |
| 5.How about the warranty? | |
| All items have 1 year guarantee. | |
| 6.How will you control the printer's quality? | |
| We fully tested every product before shipping out, and also we have QC persons. | |
| 7.Can you make OEM or ODM for products? | |
| Yes, OEM and ODM products are available. |
